1: Introduction
Wear Oil Chemical Resistant Welding Cable Flexible Copper Rubber Insulated
Conductor: Stranded bare copper flexible, fully annealed, Bare-copper.
Insulation: Ethylene Propylene Diene Monomer EPDM or EPR
Color: Black,Orange, Blue, Red etc
Products characteristics
Temperature range: EPR insulated cables should not be higher than 65°C,EPT/EPDM insulated cables should not be higher than 90°C.
VOLTAGE RATING: 450/750V, 650/1100V
2: Product Information
Origin: Xi'an, Shaanxi, China
Brand name: Woquan
Insulation material: rubber
Type: low voltage
Purpose: industrial and power cable connecting line
Conductor material: copper
Sheath: rubber, rubber sheath
Product name: welding cable
Wires: copper wires
Rated voltage: 100/100V
Flame test: VDE-0281
Standard: IEC CE UL
Cross section: 10-240mm2
Number of cores: 1 core
3: Cable Parameters
Model | H01N2-D Welding Cable |
Conductor | Class 5 copper conductor for H01N2-D Welding Cable Class 6 copper conductor for H01N2-E Welding Cable |
No. of Cores | 1 |
Conductor Type | stranded |
Insulation | Rubber |
Jacket(Sheath) | Rubber |
Test Voltage | 1.0 KV |
Nominal cross-sectional area of conductor(mm²) | 10~240(mm²) |
Application | Electric connect cable wire |
Colors | Black , Blue or Customized |
Ambient temperature | -40℃ ~+90℃ |
Max. Temperature at conductor | +120 ℃ |
AWG | Cross area mm2 | Cable diameter mm | Cable weight kg/km |
8 | 1*10 | 9.0 | 135 |
6 | 1*16 | 10.5 | 205 |
4 | 1*25 | 11.3 | 302 |
2 | 1*35 | 12.8 | 420 |
1 | 1*50 | 14.5 | 586 |
2/0 | 1*70 | 16.8 | 798 |
3/0 | 1*95 | 20.8 | 1015 |
4/0 | 1*120 | 22.3 | 1310 |
300MCM | 1*150 | 24.6 | 1620 |
350MCM | 1*185 | 25.9 | 1916 |
500MCM | 1*240 | 27.3 | 2540 |
4：Product Advantages
Wear Oil Chemical Resistant Welding Cable Flexible Copper Rubber Insulated
Good oil and chemical resistant performance
Higher flexible ,lower and high temperature ,fire retardant
With good performance under UV and Ozone conditions
5.Application Scenarios:
Wear Oil Chemical Resistant Welding Cable Flexible Copper Rubber Insulated
-Hard-hold and power supply device acc
-Day and damp interiors, as well as for limited outdoor use acc
-Light and sound technology
6.Product certification
7.About us
8.Package and Shipping
9.FAQ:
1.What's your advantage?
A: Honest business with competitive price and professional service on export process.
2. How I believe you?
A : We consider honest as the life of our company, we can tell you the contact information of our some other clients for you to check our credit. Besides, there is trade assurance from Alibaba, your order and money will be well guaranteed.
3.Can you give warranty of your products?
A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.
4.Where are you? Can I visit you?
A: Sure,welcome to you visit our factory at any time.
5.How about the delivery time?
A: Within 15-35 days after we confirm you requirement.
6.what kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
7.Q:Are you Factory or Trading Company?
A:We both are Factory and Trading Company, we offer one-stopservice about producing and selling
8.Q:What is your MOQ
A:According to different product,MOQ is about 10 to 100 pcscommonly.
9.Q:Can I get free sample?
A:Yes!lf you have placed oreder in our online store before,whenyou place order next time,we'd like to provide free sample to you
